Manual v groove Cutter,metal Strip Pcb Cutter ,guillotine for Pcb Cutter

Name: Manual v groove Cutter,metal Strip Pcb Cutter ,guillotine for Pcb Cutter
Brand: YUSH Electronic Technology Co.,Ltd
SKU: YSV-4A
Price: 10 USD
Availability: InStock

Rincian Produk

Tempat asal: Jiangsu, Tiongkok

Nama merek: YUSH

Nomor model: YSV-4A

Ketentuan Pembayaran & Pengiriman

Kuantitas min Order: 1 set

Harga: $10,000 / set

Dapatkan Harga Terbaik

Rincian Produk

Deskripsi Produk

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                manual v groove PCB cutter, metal strip PCB cutter, guillotine PCB cutter


Berat:	145kg	Lebar Pemotongan:	Lebar 75mm vertikal 380MM
Kisaran Ketebalan:	0.8-3.2 mm	Kapasitas karton:	V≥10 lubang (di atas dan di bawah 10 pisau)
Kapasitas pelat aluminium:	V≥ 5 lubang (4 pisau ke atas dan ke bawah)	Kapasitas Papan PCB:	V≥ 8 lubang (pisau atas dan bawah 8)
Kecepatan:	8 m / mnt	Motor spindle:	Inverter 3KW Motor poros plastik 3,7KW 120W motor peti mati 60W
Ukuran:	1200 mm x 980 mm x 1400 mm (L x L x T)	Komponen inti:	Motor

Berat:	145kg
Lebar Pemotongan:	Lebar 75mm vertikal 380MM
Kisaran Ketebalan:	0.8-3.2 mm
Kapasitas karton:	V≥10 lubang (di atas dan di bawah 10 pisau)
Kapasitas pelat aluminium:	V≥ 5 lubang (4 pisau ke atas dan ke bawah)
Kapasitas Papan PCB:	V≥ 8 lubang (pisau atas dan bawah 8)
Kecepatan:	8 m / mnt
Motor spindle:	Inverter 3KW Motor poros plastik 3,7KW 120W motor peti mati 60W
Ukuran:	1200 mm x 980 mm x 1400 mm (L x L x T)
Komponen inti:	Motor

Manual v groove Cutter,metal Strip Pcb Cutter ,guillotine for Pcb Cutter

Manual V-Groove Cutter - Metal Strip PCB Guillotine Cutter

Professional PCB board V-groove machine designed for precision cutting of circuit boards, metal strips, and aluminum plates. This manual guillotine-style cutter delivers consistent, clean cuts with optimal efficiency.

Operating Specifications

Product Name	PCB Board V Groove Machine (5 pairs of plastic shaft)
Cutting Width	75mm wide vertical × 380mm
Material Thickness Range	0.8 to 3.2 mm
Cutting Capacity - Cardboard	≥10 cuts per operation (10 knives above and below)
Cutting Capacity - Aluminum Plate	≥5 cuts per operation (4 knives up and down)
Cutting Capacity - PCB Board	≥8 cuts per operation (8 knives upper and lower)
Cutting Speed	8 m/min
Motor Specifications	Spindle Motor: 3KW Inverter 3.7KW Plastic Shaft Motor: 120W Close Crate Motor: 60W
Machine Dimensions	1200mm × 980mm × 1400mm (W × D × H)
Weight	145KG

Included Accessories

Gasket set
V-CUT knife (4 pieces)
Shield bearing (10 pieces)
Wrench set (various sizes)
Hex key set
Installed turret assembly
