Rincian Produk
Tempat asal: Guangdong, Tiongkok
Nama merek: YUSH
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 1 set
Harga: $10,000 / set
Berat: |
135KG |
Kekuatan: |
10 kw |
Voltase: |
220V/380V |
Model: |
YS-L530 |
Dimensi: |
P623*L737*T587mm |
Tenaga Mesin: |
3.6kw |
Watt Lebih Bersih: |
2.2KW/220V |
Dimensi Meja: |
260mm*260mm |
Kecepatan Pemotongan: |
0-100mm/dtk |
Akurasi pengulangan: |
±0,01mm |
Wilayah kerja: |
X:0-260mm, Y:0-260mm, Z:0-80mm |
Ketebalan PCB: |
0,5-5mm |
Diameter Bit Router: |
0.8-3.0mm |
Kecepatan spindel: |
60000rpm |
Pers udara: |
0.4mpa |
Berat: |
135KG |
Kekuatan: |
10 kw |
Voltase: |
220V/380V |
Model: |
YS-L530 |
Dimensi: |
P623*L737*T587mm |
Tenaga Mesin: |
3.6kw |
Watt Lebih Bersih: |
2.2KW/220V |
Dimensi Meja: |
260mm*260mm |
Kecepatan Pemotongan: |
0-100mm/dtk |
Akurasi pengulangan: |
±0,01mm |
Wilayah kerja: |
X:0-260mm, Y:0-260mm, Z:0-80mm |
Ketebalan PCB: |
0,5-5mm |
Diameter Bit Router: |
0.8-3.0mm |
Kecepatan spindel: |
60000rpm |
Pers udara: |
0.4mpa |
| Function Items | Hardware Demand |
|---|---|
| Model | YS-L530 |
| Dimension | L623*W737*H587mm |
| Power | 220V/50HZ |
| Machine Power | 3.6KW |
| Weight | About 300KG |
| Cleaner Dimension | Inside / L650*W500*H550mm |
| Cleaner Wattage | 2.2KW/220V |
| Table Dimension | 260mm*260mm |
| Cutting Speed | 0-100mm/s |
| X,Y,Z Axis Driving Speed | X, Y axis 0-1000mm/s (min), Z axis 0-750mm/s (min), servo motor drive |
| Repeatability Accuracy | ±0.01mm |
| Working Area | X:0-260mm, Y:0-260mm, Z:0-80mm |
| PCB Thickness | 0.5-5mm |
| Router Bit Diameter | 0.8-3.0mm |
| Cutting Precision | ±0.01mm |
| Cutting Ability | Linear, Circular, U-curve, Arc, L-curve |
| Cutter Change | Manual, tools needed |
| Spindle Speed | 60000rpm |
| Spindle Cooling System | Air cooling mode |
| Safety Device | Safety door and door lock sensor |
| Voice Control | ≤78 dB (measured in 1M distance) |
